Bending Roof Construction Equipment Color Steel Plate Corrugated Iron Cold Galvanizing Aluminium Roofing Sheet Making Machine

  • 2 Sets
    $7,000.00
  • >=3 Sets
    $6,000.00
Model Number:
840
Power(W):
4+4KW
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
30 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Samples: $1.00 /Set, 1 Set (Min. Order): Buy Samples
Contact Supplier
Samples - $1.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Warranty:
2 years
Type:
Tile Forming Machine
Production Capacity:
10-15m/min
Certification:
CE ISO BV
Condition:
New
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
Place of Origin:
China
Brand Name:
DIXIN
Voltage:
380V 50Hz 3phases
Weight:
3 Tons
Use:
Roof
Dimension(L*W*H):
6500*1500*1500
Tile Type:
Colored Glaze Steel
Applicable Industries:
Building Material Shops, Manufacturing Plant
Key Selling Points:
Long Service Life
product name:
roofing sheets machine
Roller material:
45# Forged Steel
Thickness:
0.3--0.8mm
Cutting blade material:
Cr 12
Diameter Of Shaft:
75mm
Control systerm:
PLC control
Color:
Blue
Middle Plate:
16mm
Usage:
roof and wall

Packaging & Delivery

Selling Units:
Single item
Single package size:
6500X1300X1500 cm
Single gross weight:
3000.000 kg
Package Type:
900 tile forming machine, steel roofing machine. 1.the pakcing of standard color steel roll forming machine is nude 2.the delivery time of standard color steel roll forming machine is 30 days 3.warranty is one year for standard color steel roll forming machine
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 30 To be negotiated

Bending Roof Construction Equipment Color Steel Plate Corrugated Iron Cold Galvanizing Aluminium Roofing Sheet Making Machine

Product Description

Panel drawing

Technical parameters:

(1) Processing material: aluzinc/galvanized steel/colored steel coil

(2) Material thickness: 0.3-0.8mm

(3) Main motor power: 4 kw

(4) Pump power: 4kw

(5) Shaft diameter: 75mm and solid forming shaft

(6) Forming steps: 15 steps.

(7) Roller material: 45# forged steel, with hard chrome plating

(8) Main frame: 350H steel

(9) Medium plate thickness: 18mm

(10) Control systerm: PLC computer control with inverter

(11) Power supply: 380V, 3 Phase, 60Hz or as your requirement

(12) 0veral sized:about 6800mm*1500mm*1500mm

Work Flow:

 Manual decoiler—Roll forming machine—PLC control—Hydraulic system —Post cut—Stacking

Some machine pictures for your reference



others machine

We can produce too many types roofing panels roll forming machine ,especially according to your request to produce.you need provide panel drawing,feeding width,effective width,and materials thickness,then we can send you more machine details.please feel free contact me.



Others Products

All these glazed tiles roof panels are very popular all over the word. It looks very beautiful.you can provide your own profile,then we produce the machine according to your request.







Our Company

Company Introduction :

 Our enterprise, Cangzhou Dixin Roll Forming Machine Co., Ltd, as the professional and leading manufacturer, can manufacture, design, installation and debug various roll forming machines and metal processing sheet equipments, which produce metal roof wall panel, glazed roof tile, CZ steel  purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping.

Backed by reasonable design, precision machining and selected material, both our standard and customized machines are characterized by long life span, precise forming and easy operation. With our customers’ trust, our machines have been sent to America, Australia, Russia, India, Sri Lanka, Nigeria, Pakistan, Uzbekistan, Mozambique, Angola, Turkey, Brazil, etc.

Warmly welcome to China to visit our factory and select the machines you need. Our address, Fuzhuang Industrial Development Zone, Botou City, Hebei Province, China













Certification



Packaging & Shipping

 Standard export packing and delivery

1. Main body of roll forming machine and decoiler is nude packing.

2. Rollers, shafts, PLC, pump and cutter are packed with water-proof plastic film, spare parts in carton box.

3. One set of machine needs a 20'container to shipping.





FAQ

Are you a trading company or manufacturer?

Manufacturer with factory

What kinds of roll forming machine do you produce?

Roof and wall panel roll forming machine, glazed tile roll forming machine, C/Z purlin roll forming machine, door frame roll forming machine, curving machine, floor deck roll forming machine, double layer roll forming machine and all kinds of roll forming machine

Is Customized filter available?

Yes,please offer your required specifications and drawing

Do you Accept OEM service?

YES!

what’s your delivery terms?

(1)FOB (2)CFR (3)CIF

What's your Delivery Time?

Normally within 30 days,please confirm with us before order!

What's the Payment Terms?

Usually,30% T/T as deposit,70% before shipment by T/T

L/C acceptable for large amount.

Scrow ,Paybal,Alipay are also ok

How you pack products?

Normally, plastic film package, fixed in container very well, we will according to customers requirement.

What's your available port of Shipment?

Main Market Western European 20%
Northern European 15%
Asia 20%
Americas 20%
Domestic Market 15%
Middle East 10%

Our Services



 After-sale

 we have a detailed instruction manual and video tutorials, or by phone, online technical support for customers. True partnership will not end at the time of delivery, we are convinced that satisfactory after-sales service is very important.

Warranty:

Whole life maintenance,Lifelong technical support;

During 12 months all parts damaged because of quality problem will be changed for free.



 if you are interested our machine ,please feel free contact Allen Li

18232811673
