Black ISO 7816 ROHS Pocket Mate USB Portable EMV Mini Smart Card Reader ACR38U-N1

  • 2-49 Pieces
    $16.00
  • 50-99 Pieces
    $12.00
  • 100-999 Pieces
    $11.00
  • >=1000 Pieces
    $9.00
Model Number:
ACR38U-NI
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customization:
Customized logo (Min. Order: 200 Pieces)
Customized packaging (Min. Order: 200 Pieces)
Samples: $16.00 /Piece, 1 Piece (Min. Order): Buy Samples
Contact Supplier
Samples - $16.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
HCCTG
Interface:
USB 2.0 full speed
Dimensions:
58.0 mm (L) x 20 mm (W) x 13.7 mm (H)
Weight:
12.0g
Supply Voltage:
Regulated 5V DC
Supply Current:
Max. 50mA
CLK Frequency:
4 MHz
MTBF:
500,00 hrs
Operating Temperature:
0-50
Compliance/Certifications:
EN 60950/IEC 60950, ISO-7816, EMV 2000 Level 1
Operating System Support:
Win98, Win ME, Win NT 4.0, Win 2000, Win 2003, Win 2003 R2, Win XP

Packaging & Delivery

Selling Units:
Single item
Single package size:
5.8X2X1.37 cm
Single gross weight:
0.01 kg
Package Type:
Neutral Packing for Black ISO 7816 ROHS Pocket Mate USB Portable EMV Mini Smart Card Reader ACR38U-N1
Lead Time :
Quantity(Piece) 1 - 50 51 - 100 101 - 500 >500
Est. Time(days) 3 15 30 To be negotiated

Black ISO 7816 ROHS Pocket Mate USB Portable EMV Mini Smart Card Reader ACR38U-N1



Feature

Supports ISO-7816 Class A, B and C ( 5V , 3V, 1.8V ) cards

1. Performs read and write operations on all microprocessor cards with T=0, T=1 protocols

2. Supports most of the popular memory card types in the market:

3. Cards following the I2C bus protocol (free memory cards) such as:
  Atmel: AT24C01 / 02 / 04 / 08 / 16 / 32 / 64 / 128 / 256 / 512 / 1024
  SGS-Thomson: ST14C02C, ST14C04C
  Gem plus: GFM1K, GFM2K, GFM4K, GFM8K

4. Cards with intelligent 256 bytes EEPROM and write protect function: SLE4432, SLE4442, SLE5532, SLE5542

5. Cards with intelligent 1K bytes EEPROM and write-protect function: SLE4418, SLE4428, SLE5518, SLE5528

6. Cards with '104' type of EEPROM (non-reloadable token counter cards): SLE4406, SLE4436, SLE5536, SLE6636

7. Cards with secure memory IC with password and authentication: AT88SC153, AT88SC1608

8. Cards with Intelligent 416-Bit EEPROM with internal PIN check: SLE4404

9. Cards with Security Logic with Application Zone: AT88SC101, AT88SC102,     AT88SC1003Supports

10. Support PPS (Protocol and Parameters Selection)

11. Short Circuit Protection

12. ROHS Compliant

13. Certificate of conformance: EN 60950/IEC 60950, ISO-7816, PC/SC, CE, FCC, CCID, Microsoft WHQL, EMV 2000 Level 1, ROHS



Specification

Dimensions

58.0 mm (L) x 20 mm (W) x 13.7 mm (H)

Weight

12.0g

Interface

USB 2.0 full speed

Supply Voltage

Regulated 5V DC

Supply Current

Max. 50mA

Operating Temperature

0-50

CLK Frequency

4 MHz

MTBF

500,00 hrs

Smart Card Interface Support

ISO-7816 Class A, B and C ( 5V, 3V, 1.8V ), T=0 and T=1

Compliance/Certifications

EN 60950/IEC 60950, ISO-7816, EMV 2000 Level 1, PC/SC, CCID, CE, FCC, ROHS, USB Full Speed Microsoft WHQL: Windows 2000, XP, Vista, 7

Operating System Support

Win98, Win ME, Win NT 4.0, Win 2000, Win 2003, Win 2003 R2, Win XP, Win Vista, Win 2008, Win 7 ,Win 2003 x64, Win 2003 R2 x64, Win XP x64, Win Vista x64, Win 2008 x64, Win 2008 R2 x64, Win 7 x64 ,Mac Linux



Application

1. e-Government

2. e-Banking  and e-Payment

3. e-Healthcare

4. Public Key Infrastructure

5. Network Security

6. Access Control

7. Loyalty Program
