CCTV Distributed Rack Mount Power Supply 16 Channel 12V DC CCTV 20Amps output, PTC Resettable Fuse

  • 1-9 Pieces
    $51.50
  • 10-49 Pieces
    $49.80
  • 50-99 Pieces
    $49.20
  • >=100 Pieces
    $48.50
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
WINTECH
Model Number:
W-12VDC-16P/20A/R
Input Voltage:
110/220VAC
Output Type:
Multiple
Output Power:
201 - 300W
Output Voltage:
12V DC
Output Frequency:
50/60HZ
Output Current:
20A
Application:
CCTV Camera
Input:
110/220VAC
Output:
12V DC
Channels:
16
Current:
20A(10A, 13A,25A 33A optional)
fuse type:
PTC
Max. Amp:
1.6 Amp/ch
G.W:
6KG
Size:
43.5*32*10mm
Warranty:
2years

Packaging & Delivery

Selling Units:
Single item
Single package size:
52X27X15 cm
Single gross weight:
5.5 kg
Package Type:
Carton for 1pcs
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 3 7 15 To be negotiated
Product Description



CCTV Distributed Rack Mount Power Supply 16 Channel 12V DC CCTV 20Amps output, PTC Resetable Fuse

Characteristics:

Input 110/220V AC
Output 12V DC,16channels
20Amp Supply Current
Integral Surge Protection
Individual LED Power Indication
Individual PTC Output Protection
Max. Amp: 1.6Amp/ch

Features:

Soft starting current, effectively reduce the impact of AC input, independent short-circuit protection and surge protection, resume automatically after clearing of fault, EMI filter, minimum ripple, 100% load test, quality guarantee, high efficiency, low T-rise, continuous duty

Input with a switch, LED indicators lighten when the power supply operates normally, and each output contains independent PTC, LED indicator, which is not interfere with each other

Convenient installation, save a lot of time and labor

Packing with color box



Specification:

Model

W- 12VDC-16P/20A

Specification

240W 12V 20A 16P

Input

Input Voltage

110/220VAC

Input Voltage Frequency

50Hz~60Hz

Average Input Current

100Vac1.6A

Efficiency

80%

Output



Output Voltage

24VDC±5%

Output Current

20A, 16 channel for 1 set load

Output Ripple Noise(Vp-p)

110mVp-p@25°C/

Rated input voltage & Output rated load

reply time of starting up

3S  Input 100Vac,Output rated load





Protection

Over voltage protection

When over voltage occurs, it will be switch to self-protection status to protect the load.

Over current protection

When over current occurs, the corresponding channel output will automatically switch to self-protection status, and the other channels output work normally, when clearing of fault, then switch back to normal.

short-circuit protection

When short-circuit occurs, individual PTC fuse will break the circuit, when clearing of fault, it switch back to normal automatically.

Circumstances

Working Temperature

0°C~+50°C

Storage temperature

-20°C~+80°C

RH

20%~90%

Heat release

Natural heat dissipation

Connection

Input

Three-pin socket



 Pictures:
