CXG80 80w Digital Thermostat Temperature Adjustable Soldering Station Repair Tools Set

  • 4-9 Pieces
    $25.00
  • 10-99 Pieces
    $21.50
  • 100-499 Pieces
    $20.50
  • >=500 Pieces
    $19.50
Model Number:
CXG80
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Customization:
Customized logo (Min. Order: 500 Pieces)
Customized packaging (Min. Order: 1000 Pieces)

More

Graphic customization (Min. Order: 1000 Pieces) Less
Samples: $25.00 /Piece, 1 Piece (Min. Order): Buy Samples
Contact Supplier
Samples - $25.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Type:
Soldering Station
Warranty:
1 year
After-sales Service Provided:
Video technical support, Online support
Place of Origin:
Guangdong, China
Brand Name:
CXG
Usage:
Tin soldering,repair
Certification:
CE ROHS FCC
Dimensions:
80(W)*130 (H)*131 (D)mm
Condition:
New
Feature:
Economical soldering station
input Voltage:
220V/110V
temperature range:
200~450°C/392-842℉
Replenishment temperature:
+-50°C
temperature constant:
+-1℃(when no work)
Material:
ESD Safe Soldering Station
Output Voltage:
24v
soldering tip:
C9
Function:
Automatic sleep function
Support:
Temperature correction function
Weight:
1.2KG

Packaging & Delivery

Selling Units:
Single item
Single package size:
29X28X13 cm
Single gross weight:
2.3 kg
Package Type:
CXG80 80w Digital Thermostat Temperature Adjustable Soldering Station Repair Tools Set packed in cartons
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 10 11 - 100 101 - 1000 >1000
Est. Time(days) 15 16 23 To be negotiated



CXG80 80w Digital Thermostat Temperature Adjustable Soldering Station Repair Tools Set

Product Specifications:
Model CXG80
HandleCXG919A
Handle length190mm
Tip supportC9
Power consumption80W
The output voltage24V
temperature stability±1 ° C (when no work)
Impedance between tip and ground2Ω or less
Potential between the tip and ground2mV or less
Heating elementCeramic heater A1365
Wire length1.2m
Body weight1.2kg
External size80(W)×130 (H)×131 (D)mm
power supply 220V/110V
temperature range200~450°C/392-842℉
Replenishment temperature+-50°C
Tip to ground resistance<2Ω
Tip to ground voltage<2mV
Package dimensions290*280*125mm
Weight/boxing number1.2kg / support, 8 / box
Packing list
CXG80 console1
soldering iron  1
power cable1
Heat resistant gasket (optional)1
Soldering iron seat1
user's manual1

Features:

1. Unique appearance design, novel color matching, compact body design, quick temperature recovery
2. Temperature correction function: when there is an error between the actual temperature of the welding tip and the set temperature, the welding table will correct the temperature of the welding tip as long as the compensation value is input
3. Automatic sleep function, energy saving, can be set 1.5.10.10.30 minutes do not use the soldering iron, this welding table automatically cool down to 200 degrees Celsius, when the soldering iron picked up again when the temperature quickly returned to the original set value
4. Turn on the soldering iron automatically. When the soldering iron is not used for 30 minutes, the welding table will turn off automatically;Please restart the machine when you want to use it again. The machine will return to the original set value within 12 seconds
5. Function prompt and fault alarm.If the parts, heating core, circuit board and other faults occur, the welding table will ring out a fault signal, prompting the staff to check
6. Plug-in temperature control prevents arbitrary change of welding temperature
7. Intelligent digital operation, microcomputer software to 5‰ second real-time tracking tip temperature, temperature is particularly stable
8. Set the lower limit function to effectively control the occurrence of welding spot false welding, which is stable and especially stable
9. Fahrenheit or Celsius temperature can be selected for operation and display

xg1.jpgxg2.jpgxg3.jpgxg4.jpgxg5.jpgxg6.jpgxg7.jpgxg8.jpgcxg-80-1.jpgcxg-80-5.jpgcxg-80-2.jpg21

Factory advantage:

Factory D&R / production/ sales/ and sales service together.

Manufactory sell directly,the goods are in plenty supply,delivery date fast,good compete price You could arrange to ship the goods by your self , or ask we help you arrange to ship. If we help you arrange to ship. Before quote the shipping freight, we need to know which model and quantity you are asking. We will according your detail address, order model and quantity to advise you ship by sea or, by air ,or by Express. As usual, we are using HongKong DHL to ship the small order.
