Compliant with 802.11b, 802.11g and 802.11n (2.4 GHz ~ 2.4835GHz)
Cheap HUAWEI HG630 ADSL2+ VDSL2 Modem
The HG630 is a new generation wireless gateway that supports very-high-data-rate digital subscriber line 2 (VDSL2). The HG630 is designed for mid-range and high-end users using high bandwidth services, such as HD video. The HG630 comes with Broadcom's latest chipset solution with the vectoring functionthat effectively solves the VDSL2 crosstalk issue. The vectoring function keeps the transmission rate at 100 Mbit/s when the user is within a range of 300 meters. Without vectoring, the transmission rate decreases to 70 Mbit/s when the user is 300 meters away. For HD video and high-speed Internet, the coverage range can be up to 800 meters (without vectoring: 500 meters). The HG630 effectively reduces the cost to carriers and guarantees high quality HD video services. Using the 802.11n and 2 x 2 multiple-input and multiple-output (MIMO) technologies, the HG630 provides wireless transmission rates of up to 300 Mbit/s, making it an ideal choice for HD video streaming and online gaming. With the DLNA function enabled on the HG630, you can built your own network access server (NAS) by connecting USB storage to the HG630's USB port.
1 A high-bandwidth DSL and 3G uplink
HG630 integrated VDSL2 and ADSL2 + compatible, high-performance network processors, and supports 3G data cards Internet through the USB interface, can provide users with a richer business experience.
2 Wireless LAN function
HG630 support multiple wireless LAN protocols: 802.11b, 802.11g, 802.11n (2.4GHz ~ 2.4835GHz). Which, 802.11n supports MIMO 2 * 2 technology, the rate can reach 300Mbps.
HG630 support multiple wireless encryption mode, you can provide secure and reliable high-speed wireless local area network users.
3 WPS function
HG630 support WPS2.0 a key secure connection, you can simply and securely configure and manage wireless networks.
HG630 supports NAT, NAPT and RIP v1/v2. Gateways can get the address through PPP mode dial, you can get the address through DHCP.
5 IPv6 features
HG630-10 support IPv6, IPv4 & IPv6 dual stack support and DS-Lite modes. Other modes can be customized to support.
6 Flexible QoS policies
HG630 supports multiple traffic classification, support PQ and WFQ queue scheduling. You can ensure that the data transmitted through a variety of different business strategies, bringing higher quality video and audio for the end user to enjoy.
7 Standardized TR-069 management
HG630 fully compatible with DSL Forum’s TR-069 specification. HG630 provide comprehensive remote management and diagnostics capabilities, enabling zero configuration solution. With automatic upgrades and service provisioning process, you can easily achieve the user's customized service provisioning, greatly reducing operational and maintenance costs.
HG630 provides Web-based configuration management page, while the Web configuration page password protection to ensure the security of user information.
3.1.1 DSL Interface
Support multiple DSL standards l VDSL2 - G.993.2 VDSL2 - VDSL2 Profiles for 8a, 8b, 8c, 8d, 12a, 12b, 17a - VDSL Vectoring l ADSL2 + - G.992.5 (G.dmt.bitplus) l ADSL2 - G.992.3 (G.dmt.bis) Annex L l ADSL - G.992.1 (G.dmt) - G.992.2 (G.lite) - G.994.1 (G.hs) - ANSI T1.413 Issue 2 Other features DSL Interface l Support multiple PVC l support manual configuration parameters PVC
3.1.2 Wireless LAN Interface Basic Specifications Wireless LAN l support multiple wireless LAN protocols - 802.11b - 802.11g - 802.11n (2.4GHz ~ 2.4835GHz) l Support WPS2.0 - Support Push Button way - Support PIN code mode l Support DQPSK, DBPSK, CCK, OFDM, BPSK, QPSK ,16-QAM ,64-QAM wireless adjustment mode l Support hidden SSID l Support multi- SSID, can be configured with four l supports multiple authentication modes on the wireless LAN interface - Open Systems (Open System) - WPA 1.0 pre-shared key (WPA-PSK) - WPA 2.0 pre-shared key (WPA2-PSK) l supports multiple encryption mode on the wireless LAN interface - WEP encryption ( 64 , 128 ) - TKIP encryption - AES encryption l supports WMM (Wi-Fi Multimedia) l support turned off or enable the wireless LAN function keys via WLAN or Web configuration interface l Support for multiple wireless terminals connected simultaneously Wireless LAN rate l 802.11b: 1Mbit / s, 2Mbit / s, 5.5Mbit / s, 11Mbit / s l 802.11g: 1Mbit / s, 2Mbit / s, 5.5Mbit / s, 6Mbit / s, 9Mbit / s, 11Mbit / s, 12Mbit / s, 18Mbit / s, 24Mbit / s, 36Mbit / s, 48Mbit / s, 54Mbit / s l 802.11n ( 2T2R antenna used ): 7.2Mbit / s, 14.4Mbit / s, 15.0Mbit / s, 21.7Mbit / s, 28.9Mbit / s, 30.0M bit / s, 43.3Mbit / s, 45.0Mbit / s, 57.8Mbit / s, 60.0Mbit / s, 65.0Mbit / s, 72.2Mbit / s, 86.7Mbit / s, 90.0Mbit / s, 115.6Mbit / s, 120.0Mbit / s, 130.0Mbit / s, 135.0Mbit / s, 144.4Mbit / s, 150.0Mbit / s, 180.0Mbit / s, 240.0Mbit / s, 270.0Mbit / s, 300.0Mbit / s 3.2 USB Interface l provides a USB Host 2.0 interface for connecting USB storage devices, printers, etc. l uplink data card support l support DLNA l support access to USB storage devices through FTP Server 3.3 Security Features l Support firewall functions l support a variety of filters - MAC address filtering - IP address filtering - URL address filtering Support ACL Support DMZ Supports multiple authentication methods - PAP - CHAP - PAP / CHAP adaptive ( default ) Support DoS attack protection - LAND - SYN ooding? - ICMP Smurf - Ping of Death - Ping Sweep - Teardrop - Unreachable - TCP / UDP PortScan - ICMP Redirection 3.4 Routing Features Support for IPv6 - Support IPv4 & IPv6 dual stack - Support for DS-Lite Supports NAT and ALG extensions Supports RIP v1 and RIP v2 PVC supports multiple operating modes PVC may need to work mode is set to any one of the following modes - IPOA - IPOE - PPPoE - PPPoA Support DHCP server, DHCP client , DHCPv6 server , DHCPv6 client and DHCP relay Support DNS server , DNS relay IGMP snooping and IGMP proxy support Support port mapping Support UpnP Support SLAAC Support SNTP 3.5 QoS features Supports the following multiple stream classification - Based on the physical port traffic classification - Based on IP addresses ( source and destination ) traffic classification - Based on port numbers ( source and destination ) traffic classification - Based on MAC addresses ( source and destination ) traffic classification - Press 802.1p traffic classification - Press and 802.1q VLAN traffic classification - Press the DSCP for traffic classification - By protocol type (TCP, UDP, ICMP) traffic classification Support convection classification marking / re-marking - Re-marks on 802.1p - On DSCP re-marking Support the priority queue scheduling mode - PQ queue scheduling mode ( supports five queues ) - WRR queue scheduling mode ( supports four queues ) 3.6 ATM features Support LLC-SNAP and VC-MUX encapsulation methods Supports ATM OAM F5 loop diagnostics Support a variety of business types : CBR, rt-VBR, nrt-VBR, UBR with PCR, UBR without PCR 3.7 Network Management Supports TR-069, TR-069 and support through remote upgrade Support System Log Viewer Support for remote and local Web management
Packaging & Shipping
Trade terms: FOB,CIF,CFR,etc
Price Terms: L/C,D/P,T/T,Western Union,PAYPAL
Payment Terms: T/T in advance
MoQ: 1 pcs
FOB Price:US $1 - 1,000 / Piece
Lead time: Within 5 working days after receipt payment.
Shipment: Express, Air, Sea
Supply capability: 200 Piece/Pieces per Week
Sample availability: Yes (not free)
Package information: carton package with the original package
We can provide detail documents and remote help for device installation and configuration.
Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
