Fully Automatic Operation Fusion Splicer machine High Precision Fiber Cleaver

FOB Reference Price:Get Latest Price
  • 1 - 9 Units
    $1,100.00
  • 10 - 29 Units
    $1,050.00
  • 30 - 99 Units
    $1,030.00
  • >=100 Units
    $980.00
Lead Time:
Quantity(Units) 1 - 10 >10
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Overview
Quick Details
Type:
Testers &Tools
Place of Origin:
Shanghai, China
Brand Name:
Baudcom - Fusion Splicer machine
Model Number:
BD-FS-40
Use:
FTTX
Function:
Fully Automatic Operation Fusion Splicer machine
Applicable Fibers:
SM, MM, DS, NZDS and others
Return Loss:
60dB
Tension Test:
2.0N
Sleeve Length:
25mm, 40mm, 50mm
Operating Temp:
-18°C~50°C
Storage Temp:
-40°C~80°C
Humidity:
0~95%RH
Dimension:
122(D)*122(W)*130(H)mm
Weight:
1.8kg(Include battery)
Application:
Submarine/Underwater Cables
Supply Ability
Supply Ability:
1000 Unit/Units per Month
Packaging & Delivery
Packaging Details
one unit per carton
Port
SHANGHAI
Lead Time :
Quantity(Units) 1 - 10 >10
Est. Time(days) 7 To be negotiated

 Fully Automatic Operation  Fusion Splicer machine High Precision Fiber Cleaver

Features
  • Compact & Light weight
  • Fully Automatic Operation
  • 5000m altitude ensures Splice Quality
  • SYSTEM TEST ensures the best working condition
  • Color LCD monitor
  • Pause function, convenient for scientific research
  • Store 8000 groups of splice results
  • USB&DC interface
  • High battery capacity, up to 260 times of continuous splice and heat





Ordering Information



BD-FS-40Fully Automatic Operation Fiber Optic Fusion Splicer
Specification



Sleeve Length

25mm, 40mm, 50mm

Splicing Program

Automatic Setting

Storage Memory

10000

Language

English, Chinese

Alignment

Core Alignment(PAS Technology)

Splice method

Arc splicing

Fiber holder

Replaceable and Suitable for the Splice of bare fiber ,pigtail ,patch cord, optical fiber drop cable and SC,FC,LC connector

Interface

USB, suitable for data download and software update

Electrode Span

At least 5000 times

Operating Temp.

-18°C~50°C

Storage Temp.

-40°C~80°C

Operating Altitude

0~5,000m

Humidity

0~95%RH

Wind Protection

max. wind velocity of 15m/s

Power Supply

AC adaptor: 85~260V input voltage;

internal battery: 12V & 10A;

DC adaptor: 12V/2A Power for external heater, light or hot jacket stripper

Battery Capacity

up to 200 times of splices and heats

Dimension

122(D)*122(W)*130(H)mm

Weight

1.8kg(Include battery)

Package

Standard Package

Model

Name

BD-FS-40

Fusion Splicer’s main body

BC5

fiber cleaver

BD-FS-40-IB

internal battery

BD-FS-40-C

charger

BD-FS-40-SE

spare electrode

BD-FS-40-ACA

AC adaptor

BD-FS-40-ACPC

AC power cord

BD-FS-40-CLS

Clauss CFS-2 fiber optic stripper

BD-FS-40-ST

cooling tray

BD-FS-40-M

manual

BD-FS-40-CS

carry case



Optional Package



Model

Name

BD-FS-40-DCA

DC adaptor

BD-FS-40-DCPC

DC power cord

Packaging & Shipping
Hot Selling FTTH Fiber Optic Machine Fusion Splicer



Production&Testing

Hot Selling FTTH Fiber Optic Machine Fusion SplicerHot Selling FTTH Fiber Optic Machine Fusion Splicer

Certifications

Hot Selling FTTH Fiber Optic Machine Fusion SplicerHot Selling FTTH Fiber Optic Machine Fusion Splicer

After-Sales Service

The goods warranty time is THREE years,we will provide best support by TEL,email,remote control or engineers in field.
Your any questions will be responsed within 2hours!
