GZM-1000 Pivoting arm drum on pallet oil additive filling equipment

  • 1-4 Sets
    $15,400.00
  • >=5 Sets
    $15,000.00
Power:
0.5kw
Model Number:
GZM-1000L
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets)
Machine customize (Min. Order: 1 Sets) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Packaging Type:
Barrel, Cans, drum
Packaging Material:
Metal, Plastic
Type:
Filling Machine
Applicable Industries:
Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Food Shop
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles
Automatic Grade:
Semi-Automatic
Driven Type:
Electric
Voltage:
AC 220V,50HZ
Place of Origin:
Shanghai, China
Brand Name:
GLZON
Dimension(L*W*H):
1500*1500*2200mm
Weight:
1000kg
Certification:
CE
After-sales Service Provided:
Online support, Video technical support
Product name:
oil additive filling machine
accuracy:
±(1~2)d(division)
Machine material:
SUS 304/Carbon steel
Filling speed:
50 barrels/hr
Max Capacity:
2000kg
Container:
208L drum/IBC barrel
Filling method:
over level/under level(with foam or not)
Conveyor:
optional
ATEX:
optional
Capping:
optional

Packaging & Delivery

Selling Units:
Single item
Single package size:
225X200X180 cm
Single gross weight:
1500.0 kg
Package Type:
oil additive filling equipment package: wooden case
Picture Example:
package-img
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Video Description

GZM-1000 Pivoting arm drum on pallet oil additive filling equipment

Product Description

 Specifications:

· Max. Capacity : 300kg X 4drums
· Division:0.2kg/drum
· Filling Capacity : 100~1200kg
· Filling Accuracy : ≤ 0.1%
· Filling Speed : 40~60 Drum/hr
· Up/Down Rang: 0-50mm(H)
· Platform: 1300X1300mm
· Barrel Dimension: ≤φ600×h950mm
· Air Pressure : 0.4~0.8Mpa
· Filling Valve:Material:SUS304/316
· Power: AC 110V/220V, 50/60Hz, 10A
· Operating Temperature:-10°C to 40°C
OPTION:
Roller Track: 1500X1300mm

For more information, please check the vedio on Youtube which we uploaded:

https://youtu.be/l7Bozz9fcLQ

Model

GZM-1000

Suitable material

Liquid like coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fineness chemical etc

Weighing form

Filling above level (liquid without foam)

Filling under level (liquid with foam)

Filling capacity

200kg*4 (pallet)

Accuracy

 0.1%

Filling speed

10-12 pallet/hour

Barrel form

Four Drums(one pallet)

Gas power

0.5MPa

Work environment

Temperature :-20~45℃relative humidity:95%(none dew)

voltage

AC 110V/220V, 50/60Hz, 10A

Max power

1KW

Filling mouth material

SUS304/SUS316

Platform size(mm)

1300*1300

Option

Stainless steel 304 conveyor roller

Conveyor customized available!

Automatic filling line available!



Basic machine! For truck lift!
