ISS 9000 IPTV OTT Vod IPTV Streaming Server DVB S DVB C IPTV Streaming Server With HLS Concurrence to 10000 users

Feedback Ratings
  • 2-4 Pieces
    $1,000.00
  • >=5 Pieces
    $500.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

software (Min. Order: 1 Pieces)
hardware (Min. Order: 1 Pieces)
Graphic customization (Min. Order: 1 Pieces) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
DIGICAST
Model Number:
ISS-9000
Product name:
IPTV OTT VOD System Streaming Server
capacity 1:
HLS Concurrence to 10000 users
Capacity 2:
HTTP Concurrence to 1000 users
Input network streams supported:
HTTP,MMS,UDP,RTSP,RTMP,HLS protocols
OUTPUTS:
support FLV, TS, MP4, UDP, HTTP
supported:
STB real-time receiving
Support:
for multiple IPTV video on demand server(FMS,Wowza,streaming,etc
Resolution:
Hardware encoding + software solution
management:
Web management

Packaging & Delivery

Selling Units:
Single item
Single package size:
58X56.5X18 cm
Single gross weight:
7.0 kg
Package Type:
ISS 9000 IPTV OTT Vod IPTV Streaming Server DVB S DVB C IPTV Streaming Server With HLS Concurrence to 10000 users packaged by 1pcs/ctn
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 1 >1
Est. Time(days) 5 To be negotiated
DVB ORDER GUIDE

DMB-90E FTA Channels Source

DMB-90E 4/8/12/16/20/24 Tuners to 256*SPTS/4*MPTS IP UDP/RTP Receiver

DMB-24E FTA 24*Tuners to RF Transmodulator

INPUT: 4/8/12/16/20/24 Tuners +32*IP SPTS input
Output :4*RF output (DVB-T/DVB-C/ISDB-T/ATSC/DTMB option)

DMB-9004CIA Encrypted Channels Source

DMB-9004CIA 4*Tuners to 48*SPTS/4*MPTS with 4*CI slot

DMB-2408 Encrypted Channels 8*Tuners Input

8*Tuners +128*IP in, 4*DVB-T/C out, 4*CI slot

DMB-9582-S2 SDI to DVB-S/S2 modulator

Inputs: 1*SDI+1*ASI; Outputs: ASI ,RF(DVB-S2) ,Built-in 10MHz reference clock and output; Support 1080P HD ,BISS Function, Adequate for DSNG system to encode SD/HD programs to DVB-S2 uplink

DMB-4000 Series IP to RF Modulator

Modulation model: MT200
Data input: 1024*IP(SPTS/MPTS) input over UDP/RTP, 2*GigE ports; Data output: 8*IP output over UDP/RTP/RTSP, 2*GigE ports; RF output (F type): 8*DVB-T/16*QAM/32*QAM/8*ATSC/6*ISDB-T non-adjacent carriers. Capable of Multiplexing.

CONTACT US
IPTV Server Family

If any new project may need the technical support , Pls feel free to contact us for Free Demo.

ORDER GUIDE
Product name
Model
Highlights








IPTV Streaming Server

ISS-9000
Classic
Input Protocol: HTTP, files
Package mode: FLV, TS, MP4, M3u8 Output Protocol: HTTP
1*10GigE network card, 1K concurrence access.


ISS-9000
Plus
Input Protocol: HTTP, RTMP, UDP, RTSP, HLS, files
Package mode: FLV, TS, MP4, M3u8 Output Protocol: HTTP, RTMP, UDP, RTSP, HLS, GRMP
1*10GigE network card, 1K concurrence access.

ISS-9000
Enhanced
Input Protocol: HTTP, files
Package mode: FLV, TS, MP4, M3u8 Output Protocol: HTTP
2*10GigE network card, 10K concurrence access.

ISS-9000
Premium
Input Protocol: HTTP, RTMP, UDP, RTSP, HLS, files
Package mode: FLV, TS, MP4, M3u8 Output Protocol: HTTP, RTMP, UDP, RTSP, HLS, GRMP
2*10GigE network card, 10K concurrence access.
Product Description

OVERVIEW

ISS-9000 IPTV Streaming Server is a professional server based on ultra-strong high-performance streaming media engines, employ new generation of architecture design, it can be used for providing distribution of high quality Audio & Video to various kinds of end-users by Internet.

The system design reaches the distributing level for ten thousand of concurrent viewers, compliant with various types of terminal devices. Owing to its powerful, fluent, stable and safe distribution capability, it is well-acclaimed. It supports H.264 & H.265 video format, easy to setup as Push mode & Pull mode of streams, output through HTTP, RTMP, HLS(m3u8) protocols, which means providing multi-screen Live Streaming, VOD services, Time-Shift and Replay through PC, mobile, TV, tablet(iOS/Android/Windows) in applications such as IPTV,OTT and other kinds of live streams. Based on the principle of saving costs for clients, the system must be able of being customized to control hardware and software budgets. The latest hardware resource is deployed according to clients' actual project scale, so as to undertake users' visit loads from scores to thousands suitable for small and big enterprises, government entities, army, groups, providing full levels of service in small size and broadcasting level operation

FEATURES

* The capability of 10K concurrent visiting.
The high-performance media engine and new generation of architecture design insure the ISS-9000 possess the capacity of Ten thousand people's concurrence easily.

* The compatibility with various kinds of end-players.
ISS-9000 realize high quality, high-speed video transmission based Internet cover all kinds of smart terminals (PC, cellphone, TVs, pad(IOS/Android/Windows))for smoothly video play.

* High compatibility with third-party encoding devices
Input/output IP streams supported: HTTP, MMS, UDP, RTSP, RTMP, HLS, GRMP, DASH( only for input) protocols.
Support Push, Pull streaming mode, Compatible with TS, MP4,FLV format packaging.


* Customizable
Able to offer/develop the API interface for integrate into customers' existing system as per needs.

* Variety in terminal play mode
ISS-9000 adopt FLV, TS packaging, support play in PC, Cellphone(Android),TVs(set top box) by using RTMP(flash) live streaming, also support slicing and pack the multi-media files, live streams to generate m3u8 index file, output HLS streams ,convenient for playing in Apple(IOS) cellphone, pad, PC. Recording file supported: AVI, TS, MP4, MPEG-1, MPEG-2, MPEG-4, WMV etc.

* Stability
Designed for broadcast level operation with Linux OS for running 24/7/365. Easy and safe to have remote access and config the server under security authorization by web-based management.

* With the VOD system integration, realize Live/VOD service on single device.

* Support video & audio pre-surveillance, detect signal errors at any time.

SPECIFICATIONS
Standard
ISO/IEC 14496-10 (H.264)
ISO/IEC 14496-3:1999 and AMD1 2000 (AAC LC)
ISO13818(MPEG-2)
Play mode
LIVE, VOD
Package Mode
FLV, TS, MP4, M3u8
Video Protocol
HTTP, MMS, UDP, RTSP, RTMP, HLS, GRMP etc.
Input
IP streams: push streaming, pull streaming
VOD: files
According to your requirements
Video format
H.264, H.265
Multimedia stream technology
HTTP dynamic adaptive DASH
Audio format
AAC, AC3, MP3
Broadcasting mode
HTTP (FLV, HTTP(ts), RTMP, HLS, DASH, GRMP
Recording format
AVI, TS, MP4, MPEG-1,MPEG-2,MPEG-4,WMV etc.;
Security
Anti-stealing-link
data layer authenticated encryption ,token authentication technology, many network authentication, Static authentication, secret key, third-party memcached authentication server
Network security
use the black and whitelist firewall settings
Player terminal
TVs(set top box),Pad, cellphone, PC and so on
Terminal system
Android, iOS(HLS section) windows and others smart Terminal
Terminal adapter
Adobe Flash Player; iPhone, iPod, iPad(IOS3.0 or later)
QuickTime Player; Safari; Android (2.0 or later) device
VLC Player; Other HLS-compatible players
Statistical monitoring
statistical data for network data broadband, users, consumption and others, monitor the consumption of CPU, internal storage, hard-disk space
Capacity
Strong load capacity, each unit ISS-9000 support up to 10K users concurrence
Stability
With broadcast level operation designed for running 7x24/365
Operating System
Industrial embedded Linux operating system
Control method
Web-based remote management, realizing the configuration through web remote operation in any device at anytime, anywhere
Resolution
160*120, 176*144, 320*240, 352*288, 352*240, 640*480, 800*600, 720*480,
720*576, 1024*576, 1024*768, 1152*864, 1280*720, 1280*800, 1280*960
1280*1024, 1300*768, 1336*768, 1360*768, 1366*768, 1440*900, 1600*900
1600*1024, 1600*1200, 1680*1050, 1920*1080, 1920*1440, 2048*1080
2560*1440, 3840*2160, 4096*2160
Frame rate:0fps, 1fps, 5fps, 10fps, 15fps, 29.97fps, 30fps, 50fps, 60fps
Video Signal Recording Frame Rate
720P: 1-60 frame
1080P:1-30 frame
4K:1-30 frame
Weight
9.5kg
Temperature
0~45℃(working), -20~80℃(storage)
Voltage
AC110V±10%, 50/60Hz
AC 220V±10%,50/60Hz
Power supply
350W
