Portable airport taxiway light/solar airport runway light/Solar kind airport light

Feedback Ratings
  • 50-99 Pieces
    US $80.00
  • >=100 Pieces
    US $70.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Type:
Aviation Obstruction Lights
Input Voltage(V):
DC3.2V(Solar Powered Way)
Lamp Power(W):
1
Lamp Luminous Flux(lm):
100%
Lamp Luminous Efficiency(lm/w):
120
CRI (Ra):
100%
Color Temperature(CCT):
red
Beam Angle(°):
360
IP Rating:
IP68
Certification:
CE, RoHS, UL
Emitting Color:
Red
Lamp Body Material:
Aluminum Alloy
Base Type:
Other
Light Source:
LED
Place of Origin:
China (Mainland)
Brand Name:
Annhung
Model Number:
AH-LS/L
Light Intensity:
≥ 32.5cd(Flash mode)
Overall Size(mm):
162 by 162 by 160
Autonomy(without sunlight):
at least 5 days(Option 20days)
Working mode:
Steady-burning mode or Flash mode(20-60times/minute)
Housing material:
Polycarbonate
Base material:
die casting aluminum
Battery materia:
lithium iron phosphate
Emitting color:
red, green, yellow,white,etc
Light source:
LED

Packaging & Delivery

Selling Units:
Single item
Single package size:
20X20X24 cm
Single gross weight:
1.5 KG
Package Type:
1 piece in 1 carton
Lead Time :
15
Specification

 Low intensity LED Solar Powered Aviation Obstruction Light

Aviation light

Solar Aviation Light

Solar Obstruction Light

Aviation Obstruction light                                                               HOT SALE! Promotion!

Applications




AH-LS/L Low-intensity Solar Powered Aviation Light can be provided with power supply without power transmission cables by solar power, so it is suitable for those locations, Electric Tower, High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV), High Pole, Tower Crane, Wind Turbine, etc especially which are hard to lay the cable or lack of power supply as well as those facilities which have high requirements on lightning protection.





Product Description



DescriptionParameter
ModeAH-LS/L
StandardICAO FAA L-810
Visible distance3.2KM
Working modeFlashing mode or Steady-burning mode
Light sourceLED
Light intensity>10cd
Vertical degree>10°
Horizontal Degree360°
Service life of LED100, 000hours
Operating voltageDC3.2V, recyclable batteries with the lightest environmental and long life
Battery capacity3.2V, 3.2Ah
AutonomyAt least 5days (Option 20days)
Overall Size (mm)Φ162 160
Installation SizeΦ140 × M6
Weight1Kg
Emitting ColorRed, Green, Yellow (Amber), Blue or White
Ambient Temperature-55℃~+60℃
Wind load80m/s
Control WayON/OFF and photocell. Light can work at night automatically by photocell.



Function

AH-LS/L Low-intensity Single Solar Powered Aviation Light has one photocell. It can work alone automatically at night by photocell when ambient brightness is lower than 500cd/m2 and close during the day.

 AH-LSC LED Solar Powered Marine Lanterns



Advantages

1.International advanced solar panel reaching at least 10 years service life.
2. Comprehensive protection in voltage short, over-voltage, floating charge and temperature.
3.Built-in Solar Panel.
4. Strong corrosion resistance, Rain and Snow, Shock and Vibrations protection and UV protection.
5. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching  100000hours.
6. Clean, renewable, green and reliable energy source.
7. Dusk-to-dawn operation: Built-in photocell inside light can let light work at night and close during the day automatically.
8. At least 5 days autonomy.
9. Recyclable batteries with the lightest environmental.

10. Small volume especially being suitable for Telecom Tower and Electric installation way.





Compliance

Low-intensity Type A or Type B FAA L-810 Low-intensity Solar-Powered Aviation Light, ICAO Annex 14 Volume 1,'Aerodrome Design and Operations’ Forth edition July 2004,table6.3

Installation Drawing

 AH-LSC LED Solar Powered Marine Lanterns
