Shielded 1X2 Port RJ45 Cat5e Multiple Ports 1*2 8p8c Modular Jacks Ethernet RJ-45 Connector

  • 1-9999 Pieces
    $0.22
  • >=10000 Pieces
    $0.20
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 100000 Pieces)
Customized packaging (Min. Order: 100000 Pieces)

More

Graphic customization (Min. Order: 100000 Pieces) Less
Contact Supplier
Samples - $0.22 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Model Number:
59A-S1208A
Application:
PCB
Place of Origin:
Guangdong, China
Housing material:
Nylon+30%.G.F 94V-0
Contact material:
Phosphor bronze 0.46mm
Plating:
Gold plating over nickel
Shield:
Copper alloy(OR steel alloy)0.20mm thickness plating ni
LED:
Option
Operating life:
750 Cycles min
Current rating:
1.5 AMP
Contact resistance:
50 Milliohms max
Insulation resistance:
500 Megohms min @ 500 VDC
Dielectric strength:
1000 VAC RMS 50Hz, 1Min
Type:
RJ45
Gender:
Female
Brand Name:
ODM

Packaging & Delivery

Selling Units:
Single item
Single package size:
0.01X0.01X0.01 cm
Single gross weight:
0.001 kg
Package Type:
durable exported carton
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 10000 10001 - 100000 >100000
Est. Time(days) 7 12 To be negotiated

Shielded 1X2 Port RJ45 Cat5e Multiple Ports 1*2 8p8c Modular Jacks Ethernet RJ-45 Connector

Please Feel Free To Contact Me And Answer Your Questions At Any Time.
Mobile / WeChat / WhatsApp+8618038084526
Skypeqinqin0508
Product Description



Housing material Nylon+30%.G.F UL94V-0
 Contact material Phosphor bronze Φ0.46mm
 Plating    Gold plating over nickel
 Shield     Copper alloy(OR steel alloy)0.20mm thickness plating ni
 LED Option
 Operating life  750 Cycles min
 Voltage rating 125 VAC RMS
 Current rating 1.5 AMP
 Contact resistance 50 Milliohms max
 Insulation resistance 500 Megohms min @ 500 VDC
 Dielectric strength 1000 VAC RMS 50Hz, 1Min
PCB retention PRE-solder 1 LB min
PCB retention Post-solder10 LBS min
Packaging & Shipping



What can we do for you?

1. We can offer free samples.

2.Various operation force, height, and color for your choice.

3. large quantity discount



Why us?

1. Excellent quality with competitive price

We are manufacturer making USB more than 5 years.

2.Quality guaranty

Check quality one by one before shipping, We have good quality-control team and precision testing machine to control the quality seriously

3. Customize acceptabl

according your design to produce quality product.





Shielded 1X2 Port RJ45 Cat5e Multiple Ports 1*2 8p8c Modular Jacks Ethernet RJ-45 Connector
Shielded 1X2 Port RJ45 Cat5e Multiple Ports 1*2 8p8c Modular Jacks Ethernet RJ-45 Connector
Shielded 1X2 Port RJ45 Cat5e Multiple Ports 1*2 8p8c Modular Jacks Ethernet RJ-45 Connector
