LoRa1276 adopts Semtech RF transceiver chip SX1276, which adopts LoRa TM Spread Spectrum modulation frequency hopping technique. The features of long distance and high sensitivity (-139 dBm) make this module perform better than FSK and GFSK module. Multi-signal won't affect each other even in crowd frequency environment; it comes with strong anti-interference performance.
Frequency Range: 868/915MHz(Customizable 137-1020 MHZ)
Sensitivity up to -139 dBm
Maximum output power: 20dBm
Sleep current <200nA
Data transfer rate:@FSK,1.2-300kbps
Lora TM ,FSK,GFSK and OOK Modulation mode
1.8-3.7 V Power supply
127 dB Dynamic Range RSSI
Packet engine up to 256 bytes with CRC
Operating Temperature Range:-40 ~ + 85 °C
Built-in temperature sensor and low battery indicator
Excellent blocking immunity
Remote meter reading
Home security alarm and remote keyless entry
home automation remote sensing
individual data records
tire pressure monitoring
wireless PC peripherals
tag reading and writing
Product name:SX1276 LoRa Module Lora1276
Working voltage range
High performance mode
Output power range
@Lora BW=125KHz_SF = 12_CR=4/5
Antenna switch control,
Tx: Txen =1, Rxen =0;
Rx: Txen = 0, Rxen = 1;
Sleep : Txen = Rxen = 0
Serial clock for SPI interface
Serial MISO for SPI interface
Serial MOSI for SPI interface
Positive power supply 3.3V
Connect with 50 ohm coaxial antenna
Products Ordering Information:
