High power board laser cutting machine1000W tsd laser equipment die cutting machinery

$75,000.00 / Set | 1 Set (Min. Order)
Model Number:
TSD-LC1000-1218 TSD-LC1000-1325
Power(W):
10000W
$75,000.00
- +
available
1500W
$75,000.00
- +
available
2000W
$75,000.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
25 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas
Applicable Material:
Acrylic, Leather, MDF, Metal, plastic, Plywood, Rubber, Wood
Laser Type:
CO2, Alial Flow CO2 Laser Tube
Cutting Area:
1200x1800mm
Cutting Speed:
>60meters/hr for 18mm Plywood)
Graphic Format Supported:
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Application:
Laser Cutting
Condition:
New
Cutting Thickness:
6-22mm Plywood, 4mm Metal
CNC or Not:
Yes
Cooling Mode:
Water Cooling
Control Software:
TSD LASER CUTTING SOFTWARE
Place of Origin:
Guangdong, China
Brand Name:
TSD
Certification:
CE, TUV
Warranty:
1 Year
Die Board CO2 Laser Cutting Machine:
Laser Cutting Machine for Die Board
Mould Knife Thickness/Slit Width:
0.45mm,0.71mm,1.05mm..etc.
Cutting Precision:
±0.05MM
Laser Power:
1500W
Re-position Accuracy:
≤0.02mm
Machine Weight:
2200Kgs
Laser Weight:
1200Kgs
Suitable Materials:
Plywood,MDF,Acryclic,Iron,Steel,Stainless Steel,Aluminum Board etc.

Packaging & Delivery

Selling Units:
Single item
Single package size:
300X22X18 cm
Single gross weight:
2300.0 kg
Package Type:
Standard Exporting Wooden Case
Picture Example:
package-img
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(days) 25 To be negotiated
Video Description

1KW Power Die Board CO2 Laser Cutting Machine Price



Welcome to Shenzhen TSD Laser Equipment Co., LTD.



This Laser Cutter is a kind of high power CO2 Laser Cutting Machine,with more widely applications,Printing,Packing,Mould Making,Advertising Signs,Metal Plates,Light-fixture,Hardware,Electrical Components,Craftworks,...etc. Industries,



there are 2models for choosing,which has different working plate,1250x800mm,1300x2500mm,OEM and ODM are welcomed.



Product Description

Picture of the High Power Metal CO2 Laser Cutting Machine:



Technical Parameter of Single Head Die Board Laser Cutter,

Model No.

TSD-LC1000-1218

TSD-LC1000-1325

Processing Scale

1250x1850mm

1300x2500mm

Machine Weight

2200Kgs

2500Kgs

Overall Dimensions

3000x220 x1800mm

3600x2300x1800mm

Laser Power

1000Watt

1500Watt

2000Watt

Laser Weight

800Kgs

1200Kgs

1200Kgs

Laser Type

Axial flow CO2 Laser Tube

Driving System

3 Axial Panasonic Servo Motor

Power Supply

380 V 50Hz 10A

Cutting Precision

±0.05mm

USB Port Connection

Yes

Operating Temperature

0-45°C

Mould Knife Thickness

0.45mm, 0.71mm,1.07mm…etc. controllable

Cutting Speed

≥60 meters per hour, 18mm plywood

Protective Gas

Dry and oil-free air

Numerical Control Panel

LCD screen, light-touched key-press

Software Supported

CorelDraw, Auto CAD, Photoshop

Graphic Format Support

PLT,DXF,BMP,JPG,GIF,PGN,TIF

EMS Memory

Attached 64 MB memory, can work under off-line condition

Auxiliary Gas

He, N2, CO2

Transmission System

Ball screw & linear guide

H.S Code

8456100090


Features:
1.Gantry structure, stable working, small floor space required for machine.
2.Laser cutting head coming with automatic touching system, adapt to the jagged materials and keep cutting kerf precision.
3.Adopt Panasonic Servo Drive and Motor system, Taiwan HIWIN precision linear guide rail to keep high precision cutting.
4.Highly effective smoke-exhausting system coming with optimized dust collector device to create healthy environment for operator.
5.Automatic gas control system to ensure low energy consumption operation power consumption and gas consumption.
6.Software is easy to operate and simple, easy to understand.
7.Be equipped with the optical path gas compensation function that can avoid difference and divergence of the beam during the conduction process by gas disturbance, and can always maintain the positive pressure of clean gas in the optical cavity to prevent external smoke and enter in.
8.Be equipped with the full compensation device in optical path of autonomous developed, to ensure the consistency of the beam diameter and the constancy of the focus in the entire range of processing.



Applications:

Applicable Industries:

Can be widely used in Printing,Packing,Mould Making,Advertising Signs,Metal Plates,Light-fixture,Hardware,Electrical Components,Craftworks,...etc. Industries.



Suitable Materials:

Plywood,Acrylic Board,MDF Board,Iron Board,Steel Board,Stainless Steel Board,Aluminum Board,Copper Board,...etc.



Finished Products---Dies Board Sample Show:

Packaging & Shipping

Sealed Stretch Film + Standard Export Wooden Case,to protect the Equipment from damage when shipping.





Certifications

CE Certification of Die Board Laser Cutting Machine:



Company Information

Shenzhen TSD Laser Equipment Co., LTD locates in Shenzhen,China and specialize in die board laser cutting machine, automatic blade bending machine development, manufacture, marketing and service which has been widely used to manufactured for packing, printing and die making industries.



Trade Shows

Our Services

Shenzhen TSD Laser Equipment Co., Ltd adheres to the customer-oriented service concept, providing complete installation, commissioning, inspection, training, maintenance and other pre-sales and after-sales service.

Pre-sales service:
We provide customers with a variety of services including production processes proposals, technical consulting, free sample making, equipment shape designing.

Machine-installation & debugging:
Qualified technician will be sent to customer’s company for machine installation and debugging. Under the proper circumstance, the technician will finish installation within three days. Please keep the installation place clean and tidy.

Training:
After machine installation and testing in the customer's company, our technician will train for the machine operation, machine maintenance, machine debugging, product sample processing, etc. TSD Laser also welcome our customers to come to Chinese headquarter for machine training. The training is free of charge and it will last at least 3 days until the operator of customers’ can use the machine properly and correctly.

Maintenance:
Complete and perfect after-sales service
One year warranty and lifetime maintenance for the equipment
Lifetime free of charge support and upgrade for hardware and software



Where are TSD Machines?

Overseas Market:

Romania,Brazil,Mexico,Colombia,Ecuador,U.A.E.,Saudi Arabia,Kuwait,Iran,Turkey,

Lebanon,Kosovo,South Africa,Algeria,Egypt,Vietnam,Bengal,Thailand,Malaysia, Singapore,Philippine,Indonesia, Sri-Lanka, India,Uzbekistan,Ukraine,Russia,…etc.

Domestic Market:

Taiwan,Hongkong,Guangdong, Jiangsu, Zhejiang, Fujian, Hunan, Jiangxi, Shandong, Sichuan, Henan , Shanxi, Shanxi, Beijing, Shanghai, Hebei, Inner Mongolia, Guangxi, ...etc.
