OD: 3.3mm 2m Extreme Flexible and Slim Micro to HDMI Cable

  • 200-999 Pieces
    $8.60
  • 1000-4999 Pieces
    $8.30
  • >=5000 Pieces
    $8.00
Color:
Black
Length:
2M
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Customization:
Customized logo (Min. Order: 1000 Pieces)
Customized packaging (Min. Order: 1000 Pieces)

More

Graphic customization (Min. Order: 1000 Pieces) Less
Samples: $10.00 /Piece, 1 Piece (Min. Order): Buy Samples
Contact Supplier
Samples - $10.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Umateck
Model Number:
H404-020
Type:
Twisted Pair
Application:
Multimedia
Packing:
Polybag
Outer Diameter:
3.3mm
Connector Color:
Gold
Connector Type:
HDMI, Micro HDMI
Shielding:
Combination, Al-Foil + Braiding
Gender:
MALE-MALE
Catagory:
Slim HDMI Cable
Connector 1:
HDMI A Male
Connector 2:
HDMI D Male
Conductor:
40AWG Tinned Sn-Copper
Color:
Black
Resolution:
4Kx2K@60Hz
Package:
Poly Bag
Certificate:
RoHS, REACH, CE

Packaging & Delivery

Selling Units:
Single item
Single package size:
10X5X1 cm
Single gross weight:
0.038 kg
Package Type:
1pc/zip bag, 200pcs/carton
Lead Time :
Quantity(Pieces) 1 - 1000 1001 - 5000 >5000
Est. Time(days) 15 25 To be negotiated
Product Description

Super Strong Anti-Jamming HDMI to Micro HDMI Cable, 2m Extreme Flexible and Slim Micro HDMI Cord, OD:3.3mm

Connect a mobile device to a display and support the latest HDMI features including Ultra HD, 4k at 50/60 (2160p). 85% thinner and 5 times more flexible than any other Micro HDMI cable in market. Even thinner and more flexible than APPLE iPod/iPhone charging USB cable. Perfect solution for fit in any tightest corner. Truly portable and small enough to fit into your pocket or the front pocket of your camera/camcorder carrier.

Key Features

• The world's thinnest and most flexible Micro HDMI cable
• 85% thinner and 5 times more flexible than other Micro HDMI cable
• Outer diameter less than 2.5mm
• Thinner than Apple USB Sync cables
• Perfect solution for fit in any tightest corner and truly portable
• Support 3D, Kx2K@60Hz (2160P, 4:4:4) Video and Audio Return Channel (ARC)
• Bandwidth up to 18Gbps
• 3 Years Warranty
Technical Spec

Electrical Characteristics
• Nominal Velocity of Propagation - 18Gbps
• DC Resistance - 300V
• Dielectric Strength - AC 500V/minute
• Insulation Resistance - 100Ω
• Nominal Attenuation - 300kHz-825MHz - <5dB, 825MHz-2.475GHz - <5dB, 2.475GHz-4.125GHz - <12dB, 4.125GHz-5.1GHz - <20dB
Physical Characteristics:
• Voltage Rating - 30V
• Maximum Bend Radius - 90mm
• Temperature Rating - 80℃
• Operating Temperature Range - -20℃- 80℃
• Storage Temperature Range - -25℃- 85℃
• Approvals – RoHS, CE, UL Compliant

Conductor 1 (10 Coaxial Conductors)
• Conductor Type - 36AWG Tinned Sn-Copper
• Spiral – 25±3/0.03 Tinned Copper

• Insulation - Foamed PE SKIN
Conductor 2 (5 Conductors)
• Conductor Type - 36AWG Tinned Copper
• Insulation - Foamed PE SKIN
Overall Cable
• Foil Shield - Aluminum Foil, 100% Coverage
• Braided Shield - 59±5/0.08 Tinned Copper
• Jacket - PVC, Black, O.D.: 3.3±0.2mm
Connector 1
• Connector Type - HDMI Type A Male
• Pin Construction - Phosphor Copper
• Injection – 45P PVC
• Plating – Gold
Connector 2
• Connector Type – Micro HDMI (Type D) Male
• Pin Construction - Phosphor Copper
• Injection – 45P PVC
• Plating – Gold

Contact us to get detailed technical data sheet by mail


Order information
Part #
Description
H404-003
World's thinnest & most Flexible Micro HDMI Cable, 40AWG, OD:2.5mm, 0.3M, Black
H404-005
World's thinnest & most Flexible Micro HDMI Cable, 40AWG, OD:2.5mm, 0.5M, Black
H404-008
World's thinnest & most Flexible Micro HDMI Cable, 40AWG, OD:2.5mm, 0.8M, Black
H404-010
World's thinnest & most Flexible Micro HDMI Cable, 40AWG, OD:2.5mm, 1M, Black
H404-012
World's thinnest & most Flexible Micro HDMI Cable, 40AWG, OD:2.5mm, 1.2M, Black
H404-015
World's thinnest & most Flexible Micro HDMI Cable, 36AWG, OD:3.3mm, 1.5M, Black
H404-020
World's thinnest & most Flexible Micro HDMI Cable, 36AWG, OD:3.3mm, 2M, Black
