Quad Band Wireless Communication module,GSM Module SIM800F the Replacement for SIM900

Feedback Ratings
  • 5-99 Pieces
    US $6.50
  • >=100 Pieces
    US $6.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
SIMCOM
Model Number:
SIM800F
Product name:
Wireless Communication GSM Module SIM800F
Quad-band:
850/900/1800/1900MHz
Dimensions:
24*24*3mm
Weight:
3.1g
Type:
SMT package
Supply voltage range:
3.4 ~ 4.4V
Operating Temperature:
-40°C ~ +85 °C
Certification:
ROHS,CE,GCF,REACH
Compability:
AT cellular command interface

Packaging & Delivery

Selling Units:
Single item
Single package size:
1X2X1 cm
Single gross weight:
0.005 KG
Lead Time :
3
Product Description
                                                        Key  Features
ProductFrequency BandsData SpeedDemensionOther Features
SIM800F

GSM/GPRS:

850/900/1800/1900MHz

Max.DL:85.6kbps

Max.UL:85.6kbps

24*24*3mm

*Control via AT commands

*TCP/UDP/FTP/HTTP/POP3/SMTP

*USB,I2C,GPIO,ADC,etc

*Bluetooth 3.0




More information

Wireless Communication GSM Module SIM800F the Replacement for SIM900



General Features•GPRS multi-slot class 12/10
•GPRS mobile station class B
•Compliant to GSM phase 2/2+
–Class 4 (2 W @850/900MHz)
–Class 1 (1 W @1800/1900MHz)
•Control via AT commands
(3GPP TS 27.007, 27.005 and SIMCom enhanced AT Commands)
•Low power consumption
Specifications for GPRS Data•GPRS class 12: max. 85.6 kbps (downlink/uplink)
•PBCCH support
•Coding schemes CS 1, 2, 3, 4
•PPP-stack
•USSD



SMS

•Point to point MO and MT
•SMS cell broadcast
•Text and PDU mode
Software features•0710 MUX protocol
•Embedded TCP/UDP protocol
•FTP/HTTP
•MMS
•POP3/SMTP
•DTMF
•Jamming  Detection
•Audio Record
•SSL
•Bluetooth 3.0 (optional)



Voice

• Tricodec
–Half rate (HR)
–Full rate (FR)
–Enhanced Full rate (EFR)
• AMR
–Half rate (HR)
–Full rate (FR)
• Hands-free operation (Echo suppression)
Interfaces68 SMT pins including
• Analog audio interface
• RTC backup
• USB interface
• Serial interface
• Interface to external SIM 3V/1.8V
• GPIO
• ADC
• PWM
• I2C
• GSM Antenna pad
• Bluetooth Antenna pad
Related Products



                                 SIM800 Series Wireless Communication GSM Module



 sim800C-GSM-GPRS-GPS-module  Quad-band-GSM-GPRS-module-SIM800H-featuring



Packaging & Shipping

Package : With Inner vacuum package & anti-static bag & individual and out carton.




Shipping :

1) Door to Door service by air -DHL, Fedex, UPS, TNT,EMS.Aramex. Advantage: Fast delivery time.
2) Sea transportation: Most cost-effective
3) Register post: China & HK register post for sample shipping, weight should be within 5kg.






Company Information

AND Technologies Co., Ltd (buypcba.com) Is a leading electronics solutions manufacturing company with the capability to cater to a wide segment of contract manufacturing services from electronic assembly of Printed

Circuit boards to production of complete ready to ship products.







FAQ

Q: What is your Lead time?

A: GSM GPS GLONASS Module & Accessories: 1~2 days for trail order,5~10 days for mass production order              A: PCB: 2 days for prototype,5~7 days for mass production
A: PCB Assembly: 1 week for prototype,3 days for Mass production

Q: What is your testing policy and how you control the quality?
A: GSM GPS GLONASS Module & Accessories: Original Brand, testing 100%
A: PCB & PCBA: For sample, usually tested by flying probe;for PCB Volume over 3 square meters, usually tested by fixture, this will be faster.Due to there's many steps to PCB production, we usually do inspection after every step.

Q: Can I visit your factory?
A: Yes, of course you are welcome to visit us. Please inform us of your visit in advance.

Q: What is the guarantee of our products?
A: 1) A year warranty;
    2) Warranty service will be honored if the damage is not caused by human;
    3) Pls send back the defective goods within the warranty period.



Contact information

Phone No.: 86-13207744612

Whatsapp: 86-13207744612



Click send now for further information for Wireless Communication GSM Module SIM800F
