Standard Double Acting Aluminium SC Series Pneumatic Air Cylinders

$8.57 - $23.43 / Piece | 10 Pieces (Min. Order)
Maximum Stroke:
50mm 75mm 100mm 125mm 175mm 200mm 250mm 300mm
Shaft Diameter:
32mm 40mm 50mm 63mm 80mm
Model Number:
SC Cylinder
$8.57
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
nonstandard (Min. Order: 10 Pieces)
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
CONO
Power:
Pneumatic
Structure:
General Cylinder
Standard or Nonstandard:
Standard
Body Material:
Aluminum
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction works , Energy & Mining

Packaging & Delivery

Selling Units:
Single item
Single package size:
50X50X50 cm
Single gross weight:
10.0 kg
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 7 To be negotiated



Bore size (mm)3240506380100
ActionDouble acting type
FuildAir(filtered through 40μ filter element)
Operating pressure0.1~0.9Mpa(1-9kgf/cm²)
Proof pressure1.35Mpa(13.5kgf/cm²)
Ambient & fluid temperature-5~70℃
CushionAir cushion
Cushion stroke24mm32mm
Port size1/8''1/4''3/8''1/2''
Body MaterialAluminum alloy



SC-1SC-2FAQ

Q1: Are factory or trading company?

A1:We are the leading manufacturer of pneumatic products who have 11 years experience. Welcome to visit our factory

at any time.



Q2:Can I get sample?

A2:I'm Sorry,Because our material cost is very high, we cannot provide you with free samples for the time being



Q3:Do you accept OEM business?

A3:Yes.We do.



Q4:What’s the payment term?

A4: T/T,Western Union,Paypal are applicable for us.



Q5: How about the warranty?

A5: 12 months under normally used.



Q6. What’s the delivery time ?

A6.. Normal model 5-7days,because we have ability to do the stock.For big order,it takes about 10-15days.



Q7: How does your factory dothe quality control?
A7: Quality is important,we always attach importance to quality control from the beginning to the end of the prodution.

Each product will be fully assembled and carefully tested before packing and shipping.
